Sharing the DNA of a cyclocross, gravel and adventure race bike, the geometry has been relaxed for long day comfort, Camino is designed to get you out there exploring the world.
We've developed the Camino to give you the perfect mix of speed and confidence. Light, zippy titanium with a slack head angle and longer wheelbase, Camino excels both loaded and unloaded, absorbing imperfections in surfaces you ride...Read more
The 2 x 11 gearing, with a whopping 11 – 32t cassette, offers a gear range that is wide enough to cope with any terrain, opening up the alpine passes to mere mortals with enough at the top end to cruise up on the flat. 2x builds give a wide gear range and keep the jumps between gears small.Read less
Tuned for long days with trail capabilty at its heart. The long wheelbase and 69° head angle make for a stable and confident ride, even over rough trails. Every size has been tuned for a 50-70mm stem so every rider gets direct and responsive steering.
The Camino swallows huge tyres. Ride 700c x 50mm or 650b x 2.2”.
Lightweight, stiff and responsive. The Camino's full carbon fork gives direct steering and smooth braking. It's completely adventure ready with mudguard and rack mounts.
Take anything anywhere. The Camino has mounts for everything you need - panniers, guards and extra mounts for adding cages to the forks. The downtube has triple cage mounts so you can set your bottle to be at a height for easy reach or lower to accommodate larger frame bags.
Revised internal cable routing with a removable port under the bottom bracket shell making cabling easy and dropping frame weight.
Stiff, secure and avoids that dreaded bottom bracket creak.
|Frame:||Camino Ti Frame V3|
|Fork:||Camino Carbon | Monocoque|
|Front derailleur:||Shimano GRX 810 | Braze-on|
|Headset:||FSA Orbit C-40-ACB|
|Shifters:||Shimano GRX 600 | 2x | 11-speed|
|Brakes:||Shimano GRX 400 | Hydraulic | Flat mount|
|Rotors:||Shimano RT66 | 160mm (front), 160mm (rear) | 6-bolt|
|Rear derailleur:||Shimano GRX 810 | 11-speed|
|Chainset:||FSA Omega | 172.5mm | 46-30t|
|Cassette:||Shimano GRX M7000 | 11-32t | 11-speed|
|Chain:||Shimano HG601 | 11-speed|
|Bottom bracket:||FSA T47 / 386EVO|
|Wheels:||Sonder Alpha 700c UK Made|
|Tyres:||Innova Gravel Mix | 700c x 40mm | Black|
|Tubes:||WTB | 700c x 38-45mm|
|Handlebars:||Sonder Bomber | 56cm|
|Stem:||Sonder Storc | 70mm|
|Seatpost:||Sonder Seatpost | 31.6mm|
|Saddle:||Sonder Abode | 138mm | Black|
|Tape:||Sonder Reels | Black|
|Frame:||S: 1.92 kg; M: 2.0 kg; L: 2.05 kg; XL: 2.16 kg (Plus fork: 0.5kg)|
|Pedals not included with full builds|
Generally we recommend: Small: Riders between 5ft 2in and 5ft 7in Medium: Riders between 5ft 6in and 5ft 10in Large: Riders between 5ft 9in and 6ft 2in X-Large: Riders 6ft 2in and over
You can also take into consideration the standover height to ensure you pick a bike that will be a good fit. If you measure your inside leg and ensure there is a minimum of an inch from the toptube to your crotch this will give you enough seatpost adjustment to find your optimum saddle height.
|ST - Seat tube||460||490||520||550|
|TT - Top tube||536||562||592||629|
|HT - Head tube||150||170||190||210|
|HA - Head angle||69||69||69||69|
|SA - Seat angle||74.5||74||74||73|
|CS - Chainstay||435||435||435||435|
|BB - BB drop||73||73||73||73|
|FO - Fork offset||50||50||50||50|
|WB - Wheelbase||1051||1073||1105||1132|
|SO - Stand over||752||773||795||815|
|RE - Reach||380||395||420||440|
|SK - Stack||563||582||600||619|
Lightweight, durable and strong titanium frame.
|Weight: S: 1.92 kg; M: 2.0 kg; L: 2.05 kg; XL: 2.16 kg (Plus fork: 0.5kg)|
|Aeronautical grade titanium|
|One piece carbon monocoque fork|
|Seatpost diameter: 31.6mm|
|Seat tube OD: 34.9mm|
|Headset: IS42/28.6 | IS52/40|
|Disc brake only|
|Mud guard and pannier rack mounts|
|700 x 50mm or 650b x 2.2” tyre clearance.|
|12mm bolt through axles at both ends.|
