Name: Camino TI Rival1 AXS XPLR Award-winning gravel bike
Brand: Sonder
Price: 3599.0 EUR
Availability: InStock
Rating: 5.00 (6 reviews)

Sale

Camino TI Rival1 AXS XPLR

Award-winning gravel bike

€3.599 €3.999

or from £550/mo

Select Options

Customize

Select Accessories

Reset

Award-winning Titanium Camino frame for off-road, on-road and everything in-between. Built with SRAM® Rival eTap AXS wireless shifting and a gravel-optimised XPLR drivetrain for all-road riding

Buy Now. Deliveries from 2 October.

Select Options

Edit

Size
- X-Small
- Small
- Medium
- Large
- X-Large
Frame Availability; Small & X-Large - In Stock Now. Medium & Large- 18/09/2023

Size:

Customize

Edit

Every Sonder bike is built to order so tell us exactly how you want it. Make any changes you want from the standard build and when you're done, just hit “Add to Bag” at the bottom of the page.

Handlebar Tape

Sonder Reels Black

+€0,00

Brooks Cambium Rubber Bar Tape [OEM] / Orange

Brooks Cambium Rubber Bar Tape / Orange

+€0,00

Grepp Handlebar Tape Ultimate Gray

+€19,99

Grepp Handlebar Tape Olivine

+€19,99

Handlebar

Sonder Bomber 56cm

+€0,00

Sonder Bomber 56cm

+€0,00

Sonder Hurricane 400mm

+€0,00

Sonder Hurricane 420mm

+€0,00

Sonder Hurricane 440mm

+€0,00

Saddle

Sonder Abode Black / 138

+€0,00

Sonder Kura

+€44,99

Sonder Zone 152 / Black

+€39,99

Brooks Cambium C17 Saddle [OEM] / All Weather / Black

Brooks Cambium C17 Saddle / All Weather / Black

+€109,99

Brooks B17 Saddle Standard / Black

+€119,99

Seatpost

Sonder Seatpost / 31.6mm / 400mm

+€0,00

Cane Creek eeSilk+ [OEM] / 31.6mm / Alloy

Cane Creek eeSilk+ / 31.6mm / Alloy

+€224,99

Sonder Seatpost / 31.6mm / 400mm

+€0,00

Cane Creek eeSilk 31.6mm / Alloy

+€199,99

Stem

Sonder Storc 60mm

+€0,00

Sonder Storc 70mm

+€0,00

Sonder Storc 80mm

+€0,00

Cane Creek eeSilk Stem [OEM] / 80mm / Black

Cane Creek eeSilk Stem / 80mm / Black Black

+€174,99

Sonder Stelo 60mm

+€39,99

Sonder Stelo 70mm

+€39,99

Sonder Stelo 80mm

+€39,99

Forks

Carbon Gravel Fork / Matte Black

+€0,00

Rockshox Rudy Ultimate XPLR / 700c / 45mm Offset / 30mm

+€499,99

Tubes

WTB Inner Tube / 700 / 38-45 Black

+€0,00

Tubeless Tyre Upgrade and Setup

+€49,99

Wheels

Sonder Alpha 700c Wheelset / UK Build XDR

+€0,00

Sonder Alpha 650b [OEM] Wheelset / UK Build

Sonder Alpha 650b Wheelset / UK Build XDR

+€0,00

Drivechain

XPLR Gears

+€0,00

Select Accessories

Edit

Bottle Cages

No Bottle Cages (none)

+€0,00

Sonder Buzz Wire Pair

+€10,99

Lights Accessories

No Bike Light Accessories (none)

+€0,00

Mudguards

No Mudguards (none)

+€0,00

Sonder Fender Front MTB

+€5,99

Pannier

No Pannier Rack (none)

+€0,00

Pedals

No Pedals (none)

+€0,00

Sonder Torque Black

+€39,99

Sonder Contact

~~+€59,99~~ +€49,99

Sonder Reko

~~+€69,99~~ +€59,99

Sonder Slingshot Black

+€74,99

Initial Price

Camino TI Rival1 AXS XPLR / Select a frame...

€3.599,00

Extras

€0,00

Total Price

€3.599,00

Buy Now. Deliveries from 2 October.

Sharing the DNA of a cyclocross, gravel and adventure race bike, the geometry has been relaxed for for long day comfort, Camino is designed to get you out there exploring the world.

At a glance

SRAM® Rival eTap AXS XPLR groupset
Camino Carbon fork
Sonder Alpha 700c UK made wheelset
Hand-welded titanium frame

We've developed the Camino to give you the perfect mix of speed and confidence. Light, zippy titanium with a slack head angle and longer wheelbase, Camino excels both loaded and unloaded, absorbing imperfections in surfaces you ride.

SRAM® Rival eTap AXS XPLR

Rival eTap AXS combines the lighter Rival 1 groupset with SRAM’s eTap wireless electronic shifting technology. Fully customisable via SRAM’s AXS smartphone app, it shifts instantly and precisely every time, completely eliminating cable stretch and housing wear, whilst leaving your bars nice and clean.

The Rival XPLR AXS gravel-specific groupset uses a 12-speed 10-44T cassette and derailleur, balancing the wide range of gearing you need for riding off-road with tight jumps for maintaining your rhythm on tarmac. Firm, powerful and well-modulated Rival hydraulic disc brakes are reliable across a wide range of riding terrains.

Features

Gravel geometry

Tuned for long days with trail capabilty at its heart. The long wheelbase and 69° head angle make for a stable and confident ride, even over rough trails. Every size has been tuned for a 50-70mm stem so every rider gets direct and responsive steering.

Wide open tyre clearance

The Camino swallows huge tyres. Ride 700c x 50mm or 650b x 2.1”.

Carbon monocoque fork

Lightweight, stiff and responsive. The Camino's full carbon fork gives direct steering and smooth braking. It's completely adventure ready with mudguard and rack mounts.

Full rack, guard and expedition mounts

Take anything anywhere. The Camino has mounts for everything you need - panniers, guards and extra mounts for adding cages to the forks. The downtube has triple cage mounts so you can set your bottle to be at a height for easy reach or lower to accommodate larger frame bags.

Internal Cable Routing

Revised internal cable routing with a removable port under the bottom bracket shell making cabling easy and dropping frame weight.

T47 Bottom Bracket

Stiff, secure and avoids that dreaded bottom bracket creak.

Build Spec

Frameset
Frame:	Camino Ti Frame V3
Fork:	Monocoque Carbon Gravel \| Matte Black
Headset:	FSA Orbit C-40-ACB

Groupset
Shifters:	SRAM Rival eTap AXS \| 12-speed
Brakes:	SRAM Rival eTap AXS \| Hydraulic
Rotors:	SRAM Centerline \| 160mm (front), 160mm (rear) \| 6-bolt
Rear derailleur:	SRAM Rival XPLR eTap AXS \| Long cage \| 12-speed
Chainset:	SRAM Rival 1 Wide \| 172.5mm \| 38t
Cassette:	SRAM XG1251 \| 10-44t \| 12-speed
Chain:	SRAM Rival \| 12-speed
Bottom bracket:	SRAM DUB / T47

Wheelset
Wheels:	Sonder Alpha 700c UK Made
Tyres:	Goodyear Connector \| 700c \| 45 \| TAN
Tubes:	WTB \| 700c x 38-45mm

Finishing kit
Handlebars:	Sonder Bomber \| 56cm
Stem:	Sonder Storc
Seatpost:	Sonder Seatpost \| 31.6mm
Saddle:	Sonder Abode
Tape:	Sonder Reels \| Black

Weight
Frame:	XS: TBC S: 1.85kg; M: 1.95kg; L: 2.0kg; XL: 2.05kg; (Plus fork: 0.5kg)
Build:	XS: TBC S: TBC M: TBC L: 9.9kg; XL: TBC

Pedals not included with full builds
Specifications are subject to change without notice

Geometry and Sizing

Sizing

Generally we recommend:
X-Small: Riders between 4ft 10in and 5ft 3in (147-160cm)
Small: Riders between 5ft 2in and 5ft 7in (158-173cm)
Medium: Riders between 5ft 6in and 5ft 10in (170-177cm)
Large: Riders between 5ft 9in and 6ft 2in (175-187cm)
X-Large: Riders 6ft 2in and over (187cm +)

You can also take into consideration the standover height to ensure you pick a bike that will be a good fit. If you measure your inside leg and ensure there is a minimum of an inch from the toptube to your crotch this will give you enough seatpost adjustment to find your optimum saddle height.

Size	X-Small	Small	Medium	Large	X-Large
ST - Seat tube	430	460	490	520	550
TT - Top tube	521.8	536.4	562.1	592.4	625.3
HT - Head tube	130	150	170	190	205
HA - Head angle	69	69	69	69	69
SA - Seat angle	74.5	74.5	74.5	74.5	74.5
CS - Chainstay	434	434	434	434	434
BB - BB drop	73	73	73	73	73
FO - Fork offset	50	50	50	50	50
WB - Wheelbase	1034.1	1050.8	1073	1105.2	1131
SO - Stand over	695.4	765.9	773	812.4	815
RE - Reach	370	380	395	420	440
SK - Stack	545.2	563.9	582.6	601.2	615

Frame Spec

Lightweight, durable and strong titanium frame.

Weight: S: 1.92 kg; M: 2.0 kg; L: 2.05 kg; XL: 2.16 kg (Plus fork: 0.5kg)
Aeronautical grade titanium
One piece carbon monocoque fork (Cage mounts on carbon fork designed for 2kg maximum load)
Seatpost diameter: 31.6mm
Seat tube OD: 34.9mm
Headset: IS42/28.6 \| IS52/40
Disc brake only
Mud guard and pannier rack mounts
700 x 50mm or 650b x 2.2” tyre clearance.
12mm bolt through axles at both ends.
Hub spacing: 100x12mm front, 142x12mm rear
