Sizing It is important to get the right size bike, if the bike fits it will be faster, more comfortable, and easier to handle. You can also take into consideration the standover height to ensure you pick a bike that will be a good fit. If you measure your inside leg and ensure there is a minimum of an inch from the toptube to your crotch this will give you enough seatpost adjustment to find your optimum saddle height.
Size Small Medium Large X-Large Rider Height 5ft 2in - 5ft 7in
(158-173cm)
5ft 6in - 5ft 10in
(170-177cm)
5ft 9in - 6ft 2in
(175-187cm)
6ft 2in +
(187cm +)
ST - Seat tube 410 440 465 495 ETT - Estimated top tube 588.9 613.1 642.4 671.5 HT - Head tube 105 120 135 150 HA - Head angle 67 67 67 67 AC - Axle to crown* 485 485 485 485 SA - Seat angle 73 73 73 73 CS - Chainstay 440-460 440-460 440-460 440-460 BB - BB drop 60 60 60 60 FO - Fork offset 45 45 45 45 WB - Wheelbase 1116.6 1142.2 1173.2 1204 SO - Stand over 735 767 782 808 RE - Reach 410 430 455 480 SK - Stack 585 598.8 612.6 626.4 AC* - 100mm fork sagged 20%
